LiTime 36V 100Ah Lithium Golf Cart battery, 200A BMS, 3840Wh Energy

【Design for Golf Carts】LiTime 36V (38.4V) 100Ah Golf Cart LiFePO4 Battery uses Automotive Grade A+ LiFePO4 Cells, having more than 4000 cycles and a 10-year lifespan.
【2C Discharging】With 2C discharging, low internal resistance and the ability to achieve a high discharge current of 650A (1s), 36V (38.4V) 100Ah Golf Cart LiFePO4 Battery is more powerful.
【Unlocking Remarkable Power】With 3840Wh capacity, a full charge of 36V (38.4V) 100Ah golf cart LiFePO4 battery supports approximately 41Miles (5.4 HP/4000W motor, 4 seats, 25℃)
【Built to Last】LiTime 36V (38.4V) 100Ah golf cart LiFePO4 battery has 200A BMS, protecting it from over current, over charging, over discharging, over circuit and over heating.
【Upgraded Performance】Reduced by 30% in volume and 63% in weight, the 36V (38.4V) 100Ah golf cart LiFePO4 battery improves the cart's maneuverability. It prolongs the service life of the cart's tires, brakes, and other components.
【Low Energy Consumption】With an ultra-low power consumption of just 71.68Wh/km, it provides substantially extended run times on each charge.
【Lower Total Cost of Ownership】No need for require intermediate replacement and regular maintenance (preventive maintenance only). The life cost at 0.1$/kWh lowers operating costs by around US$100 annually.
【Charge Swiftly】LiTime 36V (38.4V) 100Ah Golf Cart Lithium Battery supports 1C charging, with a maximum charge of about 1 hour.
【Versatile to Use】36V (38.4V) 100Ah golf cart LiFePO4 battery makes it an excellent fit for golf carts, all-terrain vehicles (ATV), electric tricycle and and other street-legal carts (≤21 mph/35km/h). Its group 8D size makes it suitable and popular for many scenarios.
$1,199.99
$1,733.32
$1,199.99
Please hurry! Only 32 left in stock
Pack: 1 Pack
Subtotal: $1,199.99

Free Shipping

Free standard shipping on all orders

Estimated to be delivered within 2-5 business days.

5 Years Warranty

Backed up by techical support within 24hrs.

Free Returns

30 Days Hassle Free Returns
LiTime 36V 100Ah Lithium Golf Cart battery, 200A BMS, 3840Wh Energy

LiTime 36V 100Ah Lithium Golf Cart battery, 200A BMS, 3840Wh Energy

$1,733.32 $1,199.99

LiTime 36V 100Ah Lithium Golf Cart battery, 200A BMS, 3840Wh Energy

$1,733.32 $1,199.99
Pack: 1 Pack

Frequently Bought Together

LiTime 36V 100Ah Lithium Golf Cart battery, 200A BMS, 3840Wh Energy 1000
$1,733.32 $1,199.99
Choose Options
Choose Options
Pack: 1 Pack
48 volt lithium golf cart battery charger 1600
$249.99 $199.99
LiTime 43.8V 18A Lithium Battery Charger for 38.4V LiFePO4 Lithium Battery 1000
$279.99 $179.99
LiTime 500A Battery Monitor With Shunt 1000
$99.99 $79.99
LiTime 275A 12-48V Battery Disconnect Switch 1000
$39.99 $23.99
Price Total: $0.00

    Customer Reviews

    Based on 1 review
    100%
    (1)
    0%
    (0)
    0%
    (0)
    0%
    (0)
    0%
    (0)
    C
    Craig Nelson
    Battery seems good but be aware of the size since it is a single battery pack.

    I have used LiTime batteries for a a few years now so I wanted to stick with a brand I trusted. This golf cart battery will hopefully continue that relationship. The battery has a physically small base footprint than the published size would indicate so be mindful of that. (hopefully they are correcting that issue with better documentation). The battery itself seems to operate as expected.. I replaced six 235Ah lead acid batteries with this single 36v 100Ah LiFePO4 golf cart battery. I did have to "rework" the battery compartment because this single battery is bigger than any one of the six it replaced. We shall see how it lasts, but given my past experience with their batteries I don't think that will be an issue.

    Customer service is something that is very important to me and the LiTime customer service has been very responsive and helpful.

    I recommend the brand. Pictures are before and after.

    LiTime Battery, Built for Golf Cart
    LiTime 36V 100Ah Golf Cart lithium Battery, born for golf carts, ensures total course conquest round after round. Whether accelerating up punishing hills or unleashing blasts of torque, golfers feel the difference of refinement with it.
    36v battery for golf cart
    Unleashing Boundless Power
    Boasting an enormous 3840Wh capacity, the LiTime 36V 100Ah lithium golf cart battery unleashes an ultra-driving range. On a full charge, it supports over 41 miles of travel, giving your cart the freedom to roam across the golf course all day long.
    36v battery for golf cart
    Full Protection
    Built with robust protection in mind, the LiTime 36V 100Ah golf cart battery utilizes a 200A BMS to safeguard its long-term reliability by protecting against overcurrent, overcharging, over-discharging, short circuits and overheating
    36v golf cart batteries
    Powerful Than Ever
    LiTime 36V/38.4V 100Ah Golf Cart lithium Battery uses Automotive Grade A+ LiFePO4 Cells. With 2C discharging, low internal resistance and the ability to achieve a high discharge current of 650A (1s), the 36V 100Ah Golf Cart LiFePO4 Battery is more powerful.
    36v golf cart battery
    Compact for Enhanced Performance
    Reduced by 30% in volume and 63% in weight, the 36V 100Ah golf cart LiFePO4 battery improves the cart's maneuverability. It prolongs the service life of the cart's tires, brakes, and other components, significantly improving the speed and torque of the golf carts
    36v golf cart batteries
    Excellence for Durability
    Compared to similar lithium batteries under the same operating conditions, the 36V 100Ah golf cart lithium battery has charge overcurrent protection to improve the cart's resistance to reverse charging
    36v golf cart batteries
    Power Up Swiftly
    LiTime 36V 100Ah Golf Cart Lithium Battery supports 1C charging, with a maximum charge of about 1 hour. Without memory effect, it can be partially or fully charged at any time.
    charge 36v golf cart batteries
    A Universal Workhorse
    With its versatile design, the 36V 100Ah LiFePO4 battery energizes a wide range of vehicles and equipment. Whether powering golf carts negotiating tight fairways or rugged ATVs tackling off-road trails, it delivers reliable muscle wherever needed (speed lower than 21 mph/35km/h).
    36v golf cart batteries
    36v golf cart batteries

    SPECS

    BATTERY
    Cell Type:
    LiFePO4 Prismatic
    Warranty:
    5 Years
    Cycle Life:
    4000 cycles at 100% DOD, 6000 cycles at 80% DOD, 15,000 cycles at 60% DOD
    Nominal Voltage:
    38.4V
    Rated Capacity:
    100Ah
    Energy:
    3840Wh
    Max. Expansion (Parallel & Series):
    4P
    Internal Resistance:
    ≤40mΩ
    Certifications:
    UL, FCC, CE, RoHS, UN38.3
    BMS
    BMS:
    200A
    Max. Continuous Output Power:
    For Golf Cart: 5000W For Energy Storage: 7680W
    Max. Continuous Charge Current:
    100A
    Max. Continuous Discharge Current:
    200A
    Max. Discharge Current 1 Second:
    650A
    CHARGE
    Charge Method:
    CC/CV
    Charge Voltage:
    43.2V±0.6V
    Recommend Charge Current:
    20A(0.2C)
    TEMPERATURE
    Charge Temperature:
    0℃ to 50℃ / 32℉ to 122℉
    Discharge Temperature:
    -20℃ to 60℃ / -4℉ to 140℉
    Storage Temperature:
    -10℃ to 50℃ / 14℉ to 122℉
    Low-Temperature Protection:
    N/A
    Low-Temperature Charging Protection Auto Recovery:
    N/A
    SELF-HEATING
    Heating Temperature:
    N/A
    Approx. Heating Time:
    N/A
    OTHERS
    Terminals:
    M8 bolts
    Weight Approx.:
    63.1 lbs
    Size:
    L20.47*W10.59*H8.66 inch (group 8D size)
    Housing Material:
    ABS (Flame Retardant Plastic)
    Protection Class:
    IP65

    FAQ

    Q: Can you convert a 36v golf cart to 48v?

    A:

    Yes, it is possible to convert a 36V golf cart to a 48V system. This conversion usually involves replacing the existing 36V battery pack, charger, controller, and potentially the motor to accommodate the higher voltage.

    Q: How fast does a 36V golf cart go?

    A:

    The speed of a 36V golf cart can vary depending on factors such as the make and model, as well as any modifications made to the cart. Generally, a stock 36V golf cart can reach speeds of around 12 to 15 miles per hour.

    Q: How many amps does a 36V golf cart draw?

    A:

    The amperage draw of a 36V golf cart varies based on factors such as terrain, weight load, and the condition of the batteries and motor. On average, it can range from 20-30 amps.

    Q: How will installing lithium batteries improve the performance of a golf cart?

    A:

    Lithium batteries can deliver more power to your golf cart than traditional lead-acid batteries. This means you can tackle hills and inclines with ease, and your golf cart will have a higher top speed.

    Q: What is the life expectancy of a lithium golf cart battery?

    A:

    Lithium batteries have a significantly longer lifespan compared to lead-acid batteries, LiTime lithium golf cart batteries can last 10+ years.

    Q: How to Charge 36V 100Ah lithium golf cart battery?

    A:

    1. LiFePO4 Battery Charger

    We recommend using a 43.8V battery charger to maximize the capacity

    Recommend charging voltage: 42.6V ~ 43.8V

    Recommend charging current: 20A (0.2C): the battery will be fully charged in around 5hrs to 100% capacity. 50A (0.5C): the battery will be fully charged in around 2hrs to around 97% capacity.

    Attention:

    Connect the charger to the battery before connecting it to the grid power in case of sparks.

    Remember to disconnect the charger from the battery after fully charging.

    Related reading: Can I Charge LiFePO4 batteries with a Normal Charger?

    2. Solar Panels

    The battery can be fully charged in one day (with effective sunshine 4.5 hrs/day) by 1200W solar panels. It may take more than one day to fully charge the battery by ≥1200W solar panels since the duration and intensity of light would be a great factor for their charging efficiency.

    3. Generator/Alternator

    If the alternator or generator supports DC output, a DC-to-DC charger is needed to connect the battery to the generator; if your alternator or generator supports AC output, please add a suitable battery charger to connect the battery and the generator according to our recommendations. The Recommended Charging Voltage: 42.6V ~ 43.8V.

    The Recommended Charging Current: ① 20A (0.2C): the battery will be fully charged in around 5 hrs to 100% capacity; ② 50A (0.5C): the battery will be fully charged in around 2 hrs to around 97% capacity.

    Q: Are LiTime LiFePO4 batteries safe?

    A:

    Yes. LiFePO4 is an inherently safe chemistry and the most stable lithium-type battery on the market. LiTime lithium cells are UL certified for the highest safety and sustainability standards. All LiTime LiFePO4 batteries come with an internal Battery Management System which protects against under-voltage during discharge, over-voltage during charge, over-current during discharge, over-temperature during charge and discharge, and short-circuit protection – protects battery cells from damage. Additionally, LiTime LiFePO4 Lithium batteries have been tested to be free from the risk of fire, and electric shock in harsh environments.

    Q: Can I use LiTime LiFePO4 Lithium batteries as starting batteries?

    A:

    No. LiTime LiFePO4 lithium batteries are not intended to be used as starting batteries but energy storage, please do not use them to start any devices.
