Redefining Limits in Size & Weight – LiTime Always Goes Beyond
Ideal for 20-30lb Trolling Motor, Fish Finder, Camping, up to 600W Wheelchairs & Mobility Scooters.
Group 22NF Battery - For 30-70lb Trolling Motor, Fish Finder, Camping, up to 1200W Wheelchair & Mobility Scooter.
2C Discharge Rate Automotive Cells LiTime 24V (25.6V) 25Ah lithium battery is made of automotive grade A cells, which have higher energy density, more stable performance, and lower self-discharge rate. The battery can support maximum 2C rate discharging and 1C rate charging. This enables it to be used in scenarios that require high currents.
Built-in 50A BMS Protection LiTime 24V 25Ah Li-FePO4 battery is equipped with 50A BMS boards. The battery management system (BMS) has the functions of over-charging, over-discharging, over-current, over-heating, and short-circuit protection, to provide comprehensive protection for both the user and the battery.
Small Size & Light Weight With high energy density which is smaller and lighter than lead-acid batteries of the same capacity, making it easier to carry and install. Therefore, the 25.6V 25Ah lithium battery can be installed to power mobility scooters and electric wheelchairs, or used as a power source for agricultural equipment and power tools, to meet the needs of most customers.
Max. 5.12kWh Energy Expansion Supports up to 4 batteries in parallel and 2 in series connections (Max. 4P2S) to form a 51.2V 100Ah battery system with a maximum energy expansion of 5.12kWh. You have more possibilities to design and create your battery system.
Purchase with Confidence Exquisite lithium battery technology enables the LiTime 25.6V 25Ah LiFePO4 battery to work brilliantly during a 10-year service life, with 4000+ cycles @100% DOD (6000 cycles @80% DOD, 15000 cycles @60% DOD). What's more, we offer a 5-year warranty and 24-hour professional technical support.
DO NOT use as Starter Battery If you need a starting battery, please consider LiTime 12V marine starting batteries series.
Usage Scenario (Wheelchair) | Recommended Amp Hours Range | Recommended LiTime Wheelchair Battery |
Short-Distance Daily Driving | 20-45Ah | 12V 45Ah Group U1 |
Urban Commuting | 30-50 Ah | 12V 45Ah Group U1 |
Outdoor Riding (Rough Terrain) | 50-70 Ah | 12V 65Ah 22NF |
All-Day Use | 70-100 Ah | 12.8V 100Ah XTRA-MINI, 12V 100Ah Group24 smart, 12V 100Ah Group24 omni |
Usage Scenario | Required Function | Description | Advantage | Recommended Battery |
Check the Battery Frequently | Smart Bluetooth 5.0 | Monitor real-time status, and discharge off or battery on/off. | Monitor the battery via your cell phone anytime anywhere. | 12V 100Ah Group24 smart, 12V 100Ah Group24 omni |
Complex Terrain | 2C Discharge Rate (High Discharge Rate) | Release power at twice its nominal capacity in a short period. | Provide a quick burst of power, for climbing ramps or quick acceleration. | 24V 25Ah |
Portable Travel | Ultra-mini & Ultra-lightweight Design | Squeezes peak performance into the smallest shell. | Improve portability and maneuverability. | 12.8V 100Ah XTRA-MINI, 12V 45Ah group U1, 12V 65Ah 22NF |
Low-temp Areas | Low-temp Cut-off Protection | <-4℉ Discharging off; <32℉ charging off. | Prevent damage from cold weather, and prolong lifespan. | 12V 45Ah Group U1, 12V 65Ah 22NF |
Low-temp Areas | Self-heating Function | Heating on: -4℉ to 41℉; Heating off: ≥50℉. | Heat to safer temp to optimize performance. | 12V 100Ah Group24 omni |
LiTime lithium batteries offer longer lifespan, lighter weight, faster charging, and consistent power output compared to traditional lead-acid batteries. They also require no maintenance and have a built-in Battery Management System (BMS) for safety.
Our lithium batteries are designed to be a drop-in replacement for most 12V lead-acid batteries used in mobility scooters and wheelchairs, like the U1 size and 22NF size battery. However, we recommend checking your device’s voltage and size specifications before purchasing.
LiTime lithium batteries can last 10+ years with up to 4000-15000 cycles, significantly longer than lead-acid batteries, which typically last 300-500 cycles.
We recommend using a lithium-compatible charger to optimize battery performance and longevity.
Our lithium batteries work well in various temperatures, but if you frequently operate in cold conditions (below 32°F / 0°C), consider our self-heating lithium batteries, which automatically warm up before charging.
Read on LiFePO4 Lithium Battery Temperature Range for more information.
Yes, you can connect LiTime lithium batteries in series (for higher voltage) or parallel (for higher capacity).
Note: To connect batteries in series or parallel, they must meet the following conditions:
LiTime lithium batteries come with a 5-year warranty and lifetime customer support for peace of mind.
Visit LiTime warranty policy for more detailed information.
